GF 16

Quick Specs

• System Type: Modular remote head & rideable crane
• Mounting for Fulcrum: GFM base
• Min. Arm Dims: 11" Reach, 20' Overall, Max Height 13'10"
• Max Remote Dims: 55'1" Reach, 65' Overall, Max Height 50'2"
• Max 2 Rider: 30'5" Reach, 40' Overall. Max Height 29'4"
• Max 1 Rider: 40'2" Reach, 50' Overall, Max Height 37'
• Max Payload Reach: Up to 30' = 550lbs, 37' = 308lbs, 40' = 286lbs, 45' = 187lbs, 51' = 176lbs, 55' = 132lbs
• Max Fulcrum Height: 9'
• Max lift range: 83'
• Max counter weight: 3,000 lbs
• Max empty crane weight: 2,580 lbs
• Max crane weight with payload: 5,712 lbs
• Type track: 39"
