Supertechno 30'

Quick Specs

• Ext. Reach From Post: 30'
• Retracted Reach From Post: 8'7"
• Rear Length From Post: 7'10"
• Max Lens Height Underslung: 30'
• Max Lens Height Overslung: 32'
• Base Width: 4'5"
• Minimum Clearance: 6'11"
• Telescopic Range: 22'
• Max Nose Load / Underslung: 186 lbs
• Max Nose Load / Overslung: N/A
• Max Speed: 9' per sec w/ speedbox
• Total Weight Incl. Payload & Counterweights: 2,640 lbs
• Empty Crane Weight: 1,459 lbs
• Empty Arm Weight: 725 lbs
